ALSTOM'S AUTOMATED CBTC TECHNOLOGY BRINGS CONNECTED AND EFFICIENT GREEN MOBILITY TO BENGALURU

Alstom has been awarded the contract to design, manufacture, supply, install, test, and commission fully automated Communications Based Train Control (CBTC) signalling system for the upcoming Bengaluru Metro Phase 2, Reach 6, 2A and 2B. The contract with Bengaluru Metro Rail Corporation (BMRCL), includes training of personnel and annual maintenance for 5 years.

This project aims to cater to the three major corridors of the Bengaluru metropolitan region, by linking the critical junction at Silk Board on the Outer Ring Road (2A) to the Kempegowda International Airport (2B) via KR Puram. Reach-6 will connect Bannerghatta Road to Nagavara with interchanges at MG Road (Purple Line which connects to Whitefield); and yellow line at Jayadeva Hospital & the Blue Line at Nagavara.

Highlights of the solutions to be delivered to Bengaluru Metro Phase 2 - Reach 6, 2A & 2B.
At the core is Alstom’s world leading CBTC technology, enabling driverless operation offering an exceptional level of service across the combined line length of 80.39 kms, this project is expected to alleviate traffic congestion in the city by minimizing travel time by at least 50%, reducing CO2 emissions, and making a substantial contribution to the expanding public infrastructure of India's Silicon Valley. Alstom’s rail cyber security solution, backed by a secure and certified development process, will deliver an efficient answer to emerging cyber threats by safeguarding the backbone of modern transportation.

To enhance passenger safety, full height platform screen doors (PSDs) will be installed at all underground stations on Reach-6 corridor and the Airport line terminal, and half-height platform screen gates (PSGs) will be installed at one at-grade station (2B corridor). PSDs at underground stations can lead to significant energy savings by reducing air-conditioning needs. This will be the first implementation of platform screen doors on Bengaluru Metro corridors.

Alstom’s CBTC Urbalis™, a solution developed in our Bangalore site with 1,000+ engineers for deployment of various solutions worldwide, will also offer the highest Grade of Automation (GoA4), which is commonly known as the ‘driverless technology’ across 50 stations and 3 depots. Alstom’s Urbalis Vision™ platform will be setup at the integrated Operation Control Centre (OCC), being built at Baiyappanahalli, and the backup Control Centre (BCC) located at Peenya, which will serve as a command centre to control and monitor all train operations. The onboard automatic train control will interface with the rolling stock manufactured by BEML, under Package 5RS-DM managing the headway and safety of 53 trains in a 6-car configuration each.

Alstom will deploy its predictive maintenance tool – HealthHub^TM, to enable real-time condition-based monitoring of the health of trains, infrastructure and signalling assets using advanced data analytics to predict the remaining useful life. This approach minimises operational downtime, maximises system availability, and optimises lifecycle costs.

This is the third contract for Alstom with BMRCL. The company is currently providing traction and power supply electrification for the 33-kilometre extension to Bangalore Metro under Phase 2. In 2009, Alstom won the contract to provide the U200 signalling and telecommunications solution for 42 kilometres of track comprising Bangalore Metro Phase I, which was completed in 2017.
